AMD A8-7680 3.5GHz Socket FM2+ Processor - Box Type (Processor Only)

The AMD A8-7680 is a desktop processor with 4 cores, launched in October 2018. It is part of the A8 lineup, using the Carrizo architecture with Socket FM2+. A8-7680 has 2 MB of L2 cache and operates at 3.5 GHz by default, but can boost up to 3.8 GHz, depending on the workload. AMD is making the A8-7680 on a 28 nm production node using 3,100 million transistors. The silicon die of the chip is not fabricated at AMD, but at the foundry of GlobalFoundries. The multiplier is locked on A8-7680, which limits its overclocking potential.

With a TDP of 45 W, the A8-7680 consumes typical power levels for a modern PC. AMD's processor supports DDR3 memory with a dual-channel interface. The highest officially supported memory speed is 2133 MT/s, but with overclocking (and the right memory modules) you can go even higher. For communication with other components in the machine, A8-7680 uses a PCI-Express Gen 3 connection. This processor features the Radeon R7 integrated graphics solution.
Hardware virtualization is available on the A8-7680, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD is including the newer AVX2 standard, too, but not AVX-512.

Physical
Socket:    AMD Socket FM2+
Foundry:    GlobalFoundries
Process Size:    28 nm
Transistors:    3,100 million
Die Size:    250 mm²
Package:    µPGA
tCaseMax:    74°C

Processor
Market:    Desktop
Production Status:    Active
Release Date:    Oct 26th, 2018
Part#:    AD7680ACABBOX AD7680ACABCBX

Performance
Frequency:    3.5 GHz
Turbo Clock:    up to 3.8 GHz
Base Clock:    100 MHz
Multiplier:    35.0x
Multiplier Unlocked:    No
Voltage:    1.275 V
TDP:    45 W

Architecture
Codename:    Carrizo
Generation:    A8
(Carrizo)
Memory Support:    DDR3
Rated Speed:    2133 MT/s
Memory Bus:    Dual-channel
ECC Memory:    No
PCI-Express:    Gen 3
Core Config

# of Cores:    4
# of Threads:    4
SMP # CPUs:    1
Integrated Graphics:    Radeon R7

Cache
Cache L1:    320 KB
Cache L2:    2 MB
