General Specifications

Platform

Desktop

Product Family

AMD Ryzen™ Processors

Product Line

AMD Ryzen™ 5 4000 G-Series Desktop Processors with Radeon™ Graphics

Former Codename

"Renoir"

Architecture

"Zen 2"

# of CPU Cores

6

Multithreading (SMT)

Yes

# of Threads

12

Max. Boost Clock

Up to 4.2GHz

Base Clock

3.7GHz

L1 Cache

384KB

L2 Cache

3MB

L3 Cache

8MB

Default TDP

65W

AMD Configurable TDP (cTDP)

45-65W

Processor Technology for CPU Cores

TSMC 7nm FinFET

Package Die Count

1

Unlocked for Overclocking

Yes

CPU Socket

AM4

Supporting Chipsets

X570

X470

X370

B550

B450

B350

A520

A320

CPU Boost Technology

Precision Boost 2

Instruction Set

x86-64

Supported Extensions

AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Max. Operating Temperature (Tjmax)

95°C

Launch Date

7/21/2020

*OS Support

Windows 11 - 64-Bit Edition

Windows 10 - 64-Bit Edition

RHEL x86 64-Bit

Ubuntu x86 64-Bit

*Operating System (OS) support will vary by manufacturer.

Connectivity

USB Type-C® Support

Yes

Native USB 3.2 Gen 2 (10Gbps) Ports

4

Native USB 3.2 Gen 1 (5Gbps) Ports

0

Native USB 2.0 (480Mbps) Ports

0

Native SATA Ports

2

PCI Express® Version

PCIe® 3.0

Native PCIe® Lanes (Total/Usable)

24 / 20

Additional Usable PCIe Lanes from Motherboard

AMD X570

16x Gen 3

AMD X470

2x Gen 3

AMD X470

8x Gen 2

NVMe Support

Boot, RAID0, RAID1, RAID10

System Memory Type

DDR4

Memory Channels

2

Max. Memory

128GB

System Memory Subtype

UDIMM

System Memory Specification

Up to 3200MT/s

Max Memory Speed

2x1R

DDR4-3200

2x2R

DDR4-3200

4x1R

DDR4-2933

4x2R

DDR4-2667

ECC Support

No

Graphics Capabilities

Integrated Graphics

Yes

Graphics Model

Radeon™ Graphics

Graphics Core Count

7

Graphics Frequency

1900 MHz

USB Type-C® DisplayPort™ Alternate Mode

Yes

Product IDs

Product ID Boxed

100-100000147BOX

Product ID Tray

100-000000147

Key Features

Supported Technologies

AMD StoreMI Technology

AMD "Zen 2" Core Architecture

AMD Ryzen™ VR-Ready Premium
