ARCTIC F14 Silent (Black) - 840033400848 (ACFAN00217A)

Brand : Arctic Cooling

SKU: SKU:  ACFAN00217A

9 in stock

Regular price ₱550.00
Regular price ₱572.00 Sale price ₱550.00
Sale! Sold out

Virtually Silent Motor

At low fan speed, the motor noise is the main source of unwanted noise. A newly developed motor with an enhanced bearing reduces friction and noise and enables almost silent operation.

Silent-Motor

Maximum Quietness, Minimum Vibration

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter.

Maximum-Quietness_EN

Innovative Design Enables Quiet and Efficient Ventilation

The innovative design of the fan blades improves the airflow and facilitates a highly efficient ventilation. The impeller was designed with a focus on minimzing the noise level yet delivering the desired airflow and pressure.

Black_Optimised_Fan_Design_New

Long Service Life

The Fluid Dynamic Bearing comes with an oil capsule that avoids lubricant leakage. Thus this bearing is as quiet as a sleeve bearing but comes with a significantly higher service life.

Fluid-Dynamic-Bearing_New_EN

Different Installation

  • Exhaust hot air out of the case
  • Intake cool air into the case
  • 3-pin connector for mainboard and power supply that also works with 4-pin headers

F14_Silent_black_intake-exhaust-in-case

TECHNICAL SPECIFICATIONS & MANUAL


General Data


Performance
Fan Speed: 800 rpm
Airflow: 46 cfm | 78 m³/h
Static Pressure: 0.45 mmH2O
Noise Level: 0.08 Sone

Fan Frame: Standard
Control Type: Fixed Speed
Connector: 3-Pin Connector
Fan Bearing: Fluid Dynamic Bearing
Operating Ambient Temperature: 0—40 °C

Electric Characteristics:
Typical Voltage: 12 V DC
Starting Voltage: 7 V
Current | Voltage: 0.11 A | 12 V DC
Cable Length: 400 mm

Size & Weight
Length: 140 mm
Width: 140 mm
Height: 27 mm
Weight: 180 g
