Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 50A continuous current for each phase, thus providing improved thermal result and superior performance.

Compared to traditional chokes, ASRock’s premium 90A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.

A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.

High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.

Graphics Engine
- AMD Radeon™ RX 6500 XT
Bus Standard
- PCI® Express 4.0 x4
DirectX
- 12 Ultimate
OpenGL
- 4.6
Memory
- 4GB GDDR6
Engine Clock
- Boost Clock: Up to 2820 MHz
- Game Clock: Up to 2650 MHz
- Base Clock: 2365 MHz
Stream Processors
- 1024
Memory Clock
- 18 Gbps
Memory Interface
- 64-bit
Resolution
- Digital Max Resolution: 7680 x 4320
Interface
- 1 x HDMI™ 2.1
- 1 x DisplayPort™ 1.4a HBR3 / DSC
HDCP
- Yes
Multi-view
- 2
Recommended PSU
- 400W
Power Connector
- 1 x 8-pin
Accessories
- 1 x Quick Installation Guide
Dimensions
- 240 x 129 x 42 mm
Net Weight
- 459 g
