DeepCool SC790 2-in-1 PWM & RGB hub (R-SC790-BKNSNN-G)
DeepCool SC790 2-in-1 PWM & RGB hub (R-SC790-BKNSNN-G)
Brand : DeepCool
Regular price
₱780.00
Sale price
₱780.00
Regular price
₱812.50
-4%
Unit price
per
Regular price
Couldn't load pickup availability
SC790
The DeepCool SC790 2-in-1 PWM & RGB hub provides fan and lighting control for up to 6 total PWM ARGB fans simultaneously while occupying minimal headers on a motherboard.
SC790
2-in-1 PWM & RGB Hub
The DeepCool SC790 2-in-1 PWM & RGB hub provides fan and lighting control for up to 6 total PWM ARGB fans simultaneously while occupying minimal headers on a motherboard.
PWM & ARGB SPLITTER HUB
The SC790 connects to a 3-pin 5V ARGB header and 4-pin PWM header on a motherboard and extends their signal to connect up to 6 PWM ARGB fans for total synchronization. The included SATA interface ensures stable continuous power for all connected devices.
The compact and sturdy case is also magnetic, allowing it to be conveniently tucked away behind the motherboard tray or positioned anywhere else.
Technical Spec
| Product Dimension | 102×60×17 mm |
| Net Weight | 69g |
| Port Type | ARGB-3Pin & PWM-4 Pin |
| Fan Ports | 6 Ports x 4Pin PWM |
| Length of Fan Connector cable | 24AWG 500 mm |
| Fan Rated Voltage | 12V DC |
| Fan Rated Current | 2.0A(1Port) / Total 4.5A(6Ports) |
| RGB Ports | 6 Ports x 3Pin Addressable RGB |
| Length of ARGB Connector cable | 24 AWG 538mm (Asus Asrock MSI) +50mm (Gigabyte) |
| RGB Rated Voltage | 5V DC |
| RGB Safety Current | 2.0A(1Port) / Total 4.5A(6Ports) |
| Power Connector | SATA Power |
| Power Safety Current | 4.5A Max |
| Mounting Method | Magnetic |
| Product Color | Black |
| EAN | 6933412796480 |
| P/N | R-SC790-BKNSNN-G |
