Fractal Design Define S2
Fractal Design Define S2
SKU: SKU: FD-CA-DEF-S2-BK-TGL
Low stock: 10 left
The Fractal Design S2 Tempered Glass comes with three preinstalled 140mm Dynamic X2 GP-14 fans, including two at the front and one at the rear of the case. Users can elect to install up to six additional fans for increased airflow. Or, taking advantage of this case's liquid cooling support, you can install radiators up to 420, 360, 280, and 120mm at the top, front, bottom, or rear of the case. If installing a top radiator, motherboard components should be limited to a height of 1.38".
Incorporating a steel frame and right-side panel, this Fractal Design case features a clear tempered-glass panel on the left side. Both of these side panels feature toolless, push-to-lock mechanisms that secure the side panels while still providing easy access. The front panel features an aluminum construction with a sound-dampening inlay, and the top panel can be removed for increased airflow or left in place for quieter operation. Removable nylon dust filters at the front, bottom, and top of the case trap dust, ensuring your build maintains a clean look. And speaking of looking clean, you can also take advantage of the PSU shroud and 0.91" of routing space to better manage cables. The front panel of the Fractal Design Define S2 Tempered Glass features a single USB 3.1 Gen 2 Type-C port, as well as two USB 3.1 Gen 1 and two USB 2.0 Type-A ports. In addition to separate 3.5mm audio input and output ports, power and reset buttons are also present.
- Seamless, scratch-resistant tempered glass side panel
- Optimized for silence with high-density industrial dampening on side, top, and front panels
- USB 3.1 Gen 2 Type-C with support for fast charging and up to 10 Gb/s transfer speeds
- Nine fan positions with clear airflow paths for cooling efficiency
- Water cooling support with room for radiators up to 420mm at the top, 360mm in the front, and 280mm at the bottom of the case
- Full-length power supply shroud hides excess cables for a clean interior and features a removable panel for installation of larger front radiators
- ModuVent technology gives users a choice between a soundproof steel cover or filtered multi-fan ventilation setup in the top panel
- Easy-to-clean nylon filters on the front, top, and base with full PSU coverage and front access for convenience
- Nexus+ Smart Hub offers control of six additional case fans and three PWM devices via your motherboard
- Three Fractal Design Dynamic X2 GP-14 140mm fans come preinstalled, providing dual intakes and a rear exhaust
- Concealed drive mounts for up to three 3.5" drives leave ample forward space for reservoirs and advanced water cooling setups
- Customizable 2.5" storage solution with two brackets and a choice of four locations to hide drives beneath the motherboard tray or display them prominently on top of the PSU shroud
- Anodized aluminum front panel with sound absorbent inlay
Motherboard Support |
ATX, E-ATX, Micro-ATX, Mini-ATX
|
External Drive Bays |
None
|
Internal Drive Bays |
3 x 2.5/3.5"
And 2 x 2.5" |
Expansion Slots |
7 x Full Height + 2
|
Maximum GPU Length |
17.32" / 440 mm
|
CPU Cooler Height |
7.28" / 185 mm
|
Supported PSU Size |
ATX
|
Maximum PSU Length |
11.81" / 300 mm
|
Fan Mounting (Front) |
3 x 120 mm
Or 3 x 140 mm |
Fan Mounting (Rear) |
1 x 120 mm
Or 1 x 140 mm |
Fan Mounting (Side) |
None
|
Fan Mounting (Top) |
3 x 120 mm
Or 3 x 140 mm |
Fan Mounting (Bottom) |
2 x 120 mm
Or 2 x 140 mm |
Fans Included (Front) |
2 x 140 mm
|
Fans Included (Rear) |
1 x 140 mm
|
Fans Included (Side) |
None
|
Fans Included (Top) |
None
|
Fans Included (Bottom) |
None
|
Maximum Radiator Size (Front) |
360 mm
|
Maximum Radiator Size (Rear) |
120 mm
|
Maximum Radiator Size (Top) |
420 mm
|
Maximum Radiator Size (Bottom) |
280 mm
|
Fans Included (Internal) |
None
|
Fan Controller Included |
Yes
|
Filter Locations |
Bottom, Front, Top
|
I/O |
2 x USB-A (USB 3.0 / 3.1/3.2 Gen 1)
2 x USB-A (USB 2.0) 1 x USB-C (USB 3.1/3.2 Gen 2) |
Audio I/O |
1 x 3.5 mm Input
1 x 3.5 mm Output |
Display Connections |
None
|
Windowed Panel |
Yes
|
Material |
Aluminum, Tempered Glass, Steel
|
Built-In Lighting |
No
|
Cable Management Space |
0.91" / 23 mm
|
Dimensions (W x H x D) |
9.17 x 18.31 x 21.38" / 233 x 465 x 543 mm
|
Weight |
25.57 lb / 11.6 kg
|
