Tech Specs
Type
Dual Chamber Mid-Tower ATX Case
Exterior Dimensions
470 x 320 x 470 mm
Volume (L)
70.7
Motherboard Sizes
ITX, mATX, ATX, EATX
Expansion Slots
7 half + 4 full height
Riser Cable Included
Yes, PCIE 4.0 x 16
I/O
1x USB-C 3.2 Gen 2, 2x USB-A 3.2 Gen 1, 1x 3.5mm Audio/Mic Combo Jack
Dust Filters
Top, Side, Bottom
Top Fans
3x 120 mm / 2x 140 mm
Top Radiator
120-360, 140-280 @ 68 mm thick
Rear Fans
1x 120/140 mm
Rear Radiator
1x 120/140 mm
Side Fans
3x 120 mm / 2x 140 mm
Side Radiator
120-360, 140-280 @ 125 mm thick
Bottom Fans
3x 120 mm / 2x 140 mm @ 32 mm thick
Max Video Card Length
422 mm
Max Video Card Thickness
105 mm
Max CPU Cooler Height
180 mm
Max PSU Length
235 mm
Storage
2x 3.5" HDD or 4x 2.5" SSD
Y70 Touch Infinite Display Specifications
14.5” 688 x 2560 (2.5K) 60Hz 5-Point Multi-Touch Capacitive Touchscreen - 183 PPI - 0.006mm Dot Pitch - 350 nits - 1500:1 Contrast Ratio - 89 Degree Viewing Angle - 20ms Pixel Response Time
Y70 Touch Display Specifications
14.1” 1100 x 3840 (4K) 60Hz 10-Point Multi-Touch Capacitive Touchscreen - 283 PPI - 0.008mm Dot Pitch - 300 nits - 1200:1 Contrast Ratio - 85 Degree Viewing Angle - 30ms Pixel Response Time
Powered By Nexus (Y70 Touch Infinite & Y70 Touch Only)
Yes, Nexus Touch
Warranty
3 Years
SKU (Non-Touch)
CS-HYTE-Y70-WW / CS-HYTE-Y70-BW / CS-HYTE-Y70-BR / CS-HYTE-Y70-B / CS-HYTE-Y70-SM / CS-HYTE-Y70-TM / CS-HYTE-Y70-BM
SKU (Touch)
CS-HYTE-Y70TI-WW / CS-HYTE-Y70TI-WB / CS-HYTE-Y70TI-BB / CS-HYTE-Y70TI-RB
