Description
Intel® Core™ i3 processor 14100F 12M Cache, up to 4.70 GHz (INTEL-BX8071514100F-99CG5J)
Intel® Core™ i3 processor 14100F (12M Cache- up to 4.70 GHz) | |
Essentials | |
Product Collection | Intel® Core™ i3 Processors (14th gen) |
Code Name | Products formerly Raptor Lake |
Vertical Segment | Desktop |
Processor Number | i3-14100F |
Lithography | Intel 7 |
Recommended Customer Price | $109.00 |
Use Conditions | PC/Client/Tablet |
CPU Specifications | |
Total Cores | 4 |
# of Performance-cores | 4 |
# of Efficient-cores | 0 |
Total Threads | 8 |
Max Turbo Frequency | 4.7 GHz |
Performance-core Max Turbo Frequency | 4.7 GHz |
Performance-core Base Frequency | 3.5 GHz |
Cache | 12 MB Intel® Smart Cache |
Total L2 Cache | 5 MB |
Processor Base Power | 58 W |
Maximum Turbo Power | 110 W |
Supplemental Information | |
Marketing Status | Launched |
Launch Date | Q1'24 |
Embedded Options Available | No |
Memory Specifications | |
Max Memory Size (dependent on memory type) | 192 GB |
Memory Types | Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 76.8 GB/s |
Expansion Options | |
Direct Media Interface (DMI) Revision | 4 |
Max # of DMI Lanes | 8 |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations ‡ | Up to 1x16+4 | 2x8+4 |
Max # of PCI Express Lanes | 20 |
Package Specifications | |
Sockets Supported | FCLGA1700 |
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2020C |
TJUNCTION | 100°C |
Package Size | 45.0 mm x 37.5 mm |
Advanced Technologies | |
Intel® Gaussian & Neural Accelerator | 3 |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Turbo Boost Technology ‡ | 2 |
Intel® Hyper-Threading Technology ‡ | Yes |
Intel® 64 ‡ | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD) | Yes |
Security & Reliability | |
Intel® Standard Manageability (ISM) ‡ | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Intel® AES New Instructions | Yes |
Secure Key | Yes |
Intel® OS Guard | Yes |
Execute Disable Bit ‡ | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
Intel® Virtualization Technology (VT-x) ‡ | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
