Linksys Business Switch - 24 Port (LGS328C) 24-Port Managed Gigabit Ethernet Switch with 4 10G SFP+ Uplinks TAA Complaint

Linksys Business Switch - 24 Port (LGS328C) 24-Port Managed Gigabit Ethernet Switch with 4 10G SFP+ Uplinks TAA Complaint

Brand : Linksys

Regular price ₱23,365.00
Sale price ₱23,365.00
Regular price ₱26,730.00 -13%
Sale! Sold out

Business Switch - 24 Port (LGS328C) 24-Port Managed Gigabit Ethernet Switch with 4 10G SFP+ Uplinks TAA Complaint

Gigabit Ethernet Switch is designed for business-class security and speed with 24 Gigabit Ethernet ports and 4 10G SFP+ uplinks.

  • 10G SFP+ Uplink Ports (4)
  • Advanced Network Security and QoS
  • TAA Compliant
Switch Type
  • Managed
Switch Ports
  • 24
Power Consumption
  • 23.95W
Jumbo Frame (FE, GE)
  • 12Kbytes
LEDs
  • Power, Fault
VLAN
  • Port-based and 802.1q VLANs, Management VLAN, Guest VLAN support
Memory
  • 512MB
Forwarding Rate
  • 95.23 Mpps
Dimensions (LxWxH)
  • (12.99 x 9.06 x 1.73 in)
  • 330 x 230 x 44 mm
Weight
  • 1989 g (4.38 lb)
Number of VLANs Supported
  • 256 active VLANs (4,096 range)
Operating Humidity
  • 10 to 90% RH
Operating Temperature
  • 0 to 45°C (32 to 113°F)
Ports
  • 24 Gigabit Ethernet
  • 4 10G SFP+
Security Features
  • 802.1x Radius authentication
  • DHCP snooping
  • DOS Attack Prevention
  • IP-MAC binding
  • Port Isolation (Protected Ports)
  • Port Security (256 max entries per port)
Rate Limiting
  • Rate limit according to network speed, 12kbps~1000Mbps: in steps of 16kbps
Power Input
  • 0.7A
  • 100–240V
  • 50–60 Hz
Spanning Tree
  • IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree, IEEE 802.1s Multiple Spanning Trees (16 instances)
Quality Of Service
  • 8 hardware queues
  • Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based
  • Strict, Weighted Round Robin (WRR)
Storage Temperature
  • 0 to 45°C (32 to 113°F)
Warranty and Support
  • 2 Year Warranty (Australia and New Zealand)
  • 5 Year Warranty (most countries)
RMON
  • Embedded remote monitoring (RMON 1, 2, 3, 9) software agent support for enhanced traffic management, monitoring, and analysis
MAC Address Table Size
  • 16K
Switching Capacity
  • 128 Gbps
HOL Blocking Prevention
  • Head of line (HOL) blocking prevention
Auto Voice VLAN
  • Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels
Other Management
  • Console Port, DHCP client, system log, configuration upload and backup via HTTP or TFTP, PING, Traceroute, dual images, SNTP
Link Aggregation
  • IEEE 802.3ad LACP, up to 8 groups with up to 8 ports per group
Access Control
  • Ingress, MC Based ACL, IPv4 Based ACL, IPv6 Based ACL, ACL Binding, Action: permit/deny
Storm Control
  • Support broadcast/unknown multicast/unknown unicast 16kbps~1000Mbps: in steps of 16kbps
Management Interface
  • HTTP
  • HTTPS
Routing
  • Static Routing, IPv4 (63 max entries), IPv6 (21 max entries)
SNMP
  • Version 1
  • Version 2c
  • Version 3
Storage Humidity
  • 5 to 95% RH (non-condensing)
IGMP Snooping
  • IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups
Power Saving
  • EEE
Port Mirroring
  • Traffic on multiple ports (up to 3 ports) can be mirrored to another port for analysis with a network analyzer
Firmware Upgrade
  • Web Browser (HTTP/HTTPS)
View full details

Description

Business Switch - 24 Port (LGS328C) 24-Port Managed Gigabit Ethernet Switch with 4 10G SFP+ Uplinks TAA Complaint

Gigabit Ethernet Switch is designed for business-class security and speed with 24 Gigabit Ethernet ports and 4 10G SFP+ uplinks.

  • 10G SFP+ Uplink Ports (4)
  • Advanced Network Security and QoS
  • TAA Compliant
Switch Type
  • Managed
Switch Ports
  • 24
Power Consumption
  • 23.95W
Jumbo Frame (FE, GE)
  • 12Kbytes
LEDs
  • Power, Fault
VLAN
  • Port-based and 802.1q VLANs, Management VLAN, Guest VLAN support
Memory
  • 512MB
Forwarding Rate
  • 95.23 Mpps
Dimensions (LxWxH)
  • (12.99 x 9.06 x 1.73 in)
  • 330 x 230 x 44 mm
Weight
  • 1989 g (4.38 lb)
Number of VLANs Supported
  • 256 active VLANs (4,096 range)
Operating Humidity
  • 10 to 90% RH
Operating Temperature
  • 0 to 45°C (32 to 113°F)
Ports
  • 24 Gigabit Ethernet
  • 4 10G SFP+
Security Features
  • 802.1x Radius authentication
  • DHCP snooping
  • DOS Attack Prevention
  • IP-MAC binding
  • Port Isolation (Protected Ports)
  • Port Security (256 max entries per port)
Rate Limiting
  • Rate limit according to network speed, 12kbps~1000Mbps: in steps of 16kbps
Power Input
  • 0.7A
  • 100–240V
  • 50–60 Hz
Spanning Tree
  • IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree, IEEE 802.1s Multiple Spanning Trees (16 instances)
Quality Of Service
  • 8 hardware queues
  • Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based
  • Strict, Weighted Round Robin (WRR)
Storage Temperature
  • 0 to 45°C (32 to 113°F)
Warranty and Support
  • 2 Year Warranty (Australia and New Zealand)
  • 5 Year Warranty (most countries)
RMON
  • Embedded remote monitoring (RMON 1, 2, 3, 9) software agent support for enhanced traffic management, monitoring, and analysis
MAC Address Table Size
  • 16K
Switching Capacity
  • 128 Gbps
HOL Blocking Prevention
  • Head of line (HOL) blocking prevention
Auto Voice VLAN
  • Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels
Other Management
  • Console Port, DHCP client, system log, configuration upload and backup via HTTP or TFTP, PING, Traceroute, dual images, SNTP
Link Aggregation
  • IEEE 802.3ad LACP, up to 8 groups with up to 8 ports per group
Access Control
  • Ingress, MC Based ACL, IPv4 Based ACL, IPv6 Based ACL, ACL Binding, Action: permit/deny
Storm Control
  • Support broadcast/unknown multicast/unknown unicast 16kbps~1000Mbps: in steps of 16kbps
Management Interface
  • HTTP
  • HTTPS
Routing
  • Static Routing, IPv4 (63 max entries), IPv6 (21 max entries)
SNMP
  • Version 1
  • Version 2c
  • Version 3
Storage Humidity
  • 5 to 95% RH (non-condensing)
IGMP Snooping
  • IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups
Power Saving
  • EEE
Port Mirroring
  • Traffic on multiple ports (up to 3 ports) can be mirrored to another port for analysis with a network analyzer
Firmware Upgrade
  • Web Browser (HTTP/HTTPS)
