Features
-Power-Over-Ethernet (PoE) and PoE+ options available for powering IP Security Cameras, VoIP phones, wireless access points, and other PoE-powered devices
-These PoE+ Switches are not just flexible in terms of placement they are also flexible in terms of PoE power
-Built-in PoE power selector switch that allow for optional / interchangeable power adapters* (sold separately) that can be used to increase (or decrease) the PoE power available on the switch
-The flexible mounting system gives you the flexibility to place them in a desktop environment, wall mount them, or even rack-mount (accessories included)
GS116LP FEATURES
-PLUG AND PLAY: Simple setup with no software or configuration needed.
-POWER-OVER-ETHERNET:
-16 PoE+ ports with 183W total power budget, and includes NETGEAR FlexPoE allowing to reduce the power budget to 155W or even 76W (w/separately purchased power supply modules)
-FLEXIBLE MOUNTING: Mount on rack, desktop, or wall.
-SMALL SIZE, METAL CASE AND SILENT OPERATION: Durable quality, space saver, and quietness for peace of mind.
-LIFETIME LIMITED WARRANTY & NEXT BUSINESS DAY REPLACEMENT: NETGEAR has your back to ensure your network is up and running.
-STURDY METAL CASE, DESKTOP/RACKMOUNT FORM FACTOR WITH QUIET FANS: Can be placed on desk or on mounted rack and will operate quietly with assured durability.
EXTENDED FEATURES
-Choice of Fast Ethernet and Gigabit Ethernet connectivity
-Energy-efficient technology for power savings
-PoE power auto-balance - the switch automatically balances the PoE power based on the device needs independent of PoE class detected, at a very granular level.
--Auto-MDI/MDIX eliminates the need for crossover cables
-Non-blocking switching architecture for maximum throughput at wire speed
-Auto negotiation for automatic connection at the highest common speed between switch and an end device
-Power-over-Ethernet (PoE) option available for powering IP Security Cameras, VoIP phones, wireless access points, and other PD-powered devices
-Desktop or rackmountable
POE+ FEATURES
-Power-Over-Ethernet (PoE) and PoE+ options available for powering IP Security Cameras, VoIP phones, wireless access points, and other PoE-powered devices
-These PoE+ Switches are not just flexible in terms of placement they are also flexible in terms of PoE power
-Built in PoE power selector switch that allow for optional / interchangeable power adapters* (sold separately) that can be used to increase (or decrease) the PoE power available on the switch
-The flexible mounting system gives you the flexibility to place them in a desktop environment, wall mount them, or even rack-mount (accessories included)
Technical Specifications
PHYSICAL SPECIFICATION
-
Dimensions (WxDxH) @mm : 286 x 102 x 27 mm
-
Weight (kg) : 0.88 kg
-
MTBF (hours) : 2,088,514 hours
TECHNICAL SPECS
-
Speed : 10/100/1000Mbps Gigabit Ethernet
-
Number of Ports : 16
-
PoE ports : 16 PoE+ ports , up to 30W per port
-
Total PoE Budget : 76W
-
Loop Detection : n/a
-
Short cable power saving : Yes
-
Energy Efficient Ethernet Support (IEEE 802.3az) : Yes
-
Jumbo Frame Support : Yes
-
Queue WRR Ratio : 1:3:5:7:8:10:12:15
-
MAC Table Size : 4K
-
Packet buffer size : 1MB
-
IEEE 802.1p QoS : Yes
-
Max Power Consumption : 90W
-
FCC Class : B
REQUIREMENTS
-
Operating Temperature : 0 to 40ºC
