SEASONIC X-Series 650W Power Supply X650 SS-650KM3 80PLUS® Gold Intel ATX 12 V Fully modular

SEASONIC X-Series 650W Power Supply X650 SS-650KM3 80PLUS® Gold Intel ATX 12 V Fully modular

Brand : SEASONIC

SKU:  SS-650KM3

₱6,684.00
₱7,798.00 ₱6,684.00
Sale! Sold out
Taxes included.

Low stock: 1 left

X-SERIES

The Seasonic X-Series was pioneering in obtaining the industry’s first 80 PLUS® Gold certification in 2009. Its 80 PLUS® Gold efficiency rating guarantees that efficiency will stay above 87 % at all loading levels. Moreover, the X-Series is also compliant with the Energy Star 5.0 rating and reduces energy consumption under standby, sleep and idle mode. This Seasonic market leader series it is a true representative of Green PC technology, which has many built-in features to help computer users lower their electricity bills. These power supplies are real top performers in Seasonic’s fully modular, multi-output ATX power supply family. All X-Series units also feature a patented design of DC Connector Module with Integrated VRM, with which these units achieve near-perfect DC-to-DC conversion, along with a true power factor above 0.9.

  • ATX 12 V
  • Fully modular
  • 80 PLUS Gold Certified
  • 7 Years Warranty
  • Dimensions: 150 mm (W) x 190 mm (L) x 86 mm (H)
  • Dimensions: 150 mm (W) x 160 mm (L) x 86 mm (H)



\

FEATURE SUMMARY

  • 80 PLUS® Gold certified
  • Stable Voltage Regulation (2 %)
  • DC to DC Converter Design
  • S3FC - Fanless until 30 % load
  • Multi-GPU setup
  • Gold plated connectors
  • 7 years warranty

SPECIFICATIONS

SS-650KM3

Technical Specifications
80PLUS® Gold
Form Factor Intel ATX 12 V
Dimensions 150 mm (W) x 160 mm (L) x 86 mm (H)
Fan Information Fan Size 120 mm
Fan Control Seasonic S3FC
Fan Bearing Double Ball Bearing
Life Expectancy 70,000 at 40 °C, 15 % - 65 % R.H.
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, Gost-R, CB , BSMI, CCC, CE, FCC, RCM
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 7 Years
Power Output
AC Input Voltage: 100 V - 240 V
Current: 8.5-4 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 54 A 0.5 A 3 A
125 W 648 W 6 W 15 W
Total continuous power 650 W

CABLES

SS-650KM3

Connector Connector Count Cable Length
Main Power (24/20 pins) 1 1 x 610 mm - modular
CPU (8/4 pins) 2 1 x 650 mm - 8/4pins modular
1 x 650 mm - 8 pins modular
PCIe (8/6 pins) 4 2 x 550 + 100 mm - modular
SATA 10 2 x 400 + 120 + 120 + 120 mm - modular
1 x 300 + 120 mm - modular
Peripheral 5 1 x 400 + 120 + 120 mm - modular
1 x 300 + 120 mm - modular
Floppy 1 1 x 101 mm - modular

Specifications are subject to change without prior notice.
