SEASONIC Platinum Series SS-1050XP3 1050W 80 Plus Platinum Modular Power Supply

SEASONIC Platinum Series SS-1050XP3 1050W 80 Plus Platinum Modular Power Supply

Brand : SEASONIC

SKU:  SS-1050XP3

₱12,600.00
₱14,700.00 ₱12,600.00
Sale! Sold out
Taxes included.

Low stock: 2 left

PLATINUM SERIES

The Seasonic Platinum Series achieves extremely high power conversion efficiency and unbelievably tight 2 % voltage regulation.  Every model features a patented DC Connector Module Back Panel with Integrated VRM and LLC/Full-bridge circuit topology. The Platinum series defines what genuine premium power supplies should be by delivering the complete package; ultra-high efficiency, excellent dynamic response, and customizable cable arrangement that can be tailored to meet any individual needs.

  • ATX 12 V
  • Fully modular
  • 80 PLUS Platinum Certified
  • 7 Years Warranty
  • Dimensions: 150 mm (W) x 190 mm (L) x 86 mm (H)
  • Dimensions: 150 mm (W) x 160 mm (L) x 86 mm (H)

FEATURE SUMMARY

  • 80 PLUS® Platinum certified
  • Stable Voltage Regulation (2 %)
  • DC to DC Converter Design
  • S3FC - Fanless until 30 % load
  • Multi-GPU setup
  • Gold plated connectors
  • 7 years warranty



SPECIFICATIONS

SS-1050XP3

Technical Specifications
80PLUS® Platinum
Form Factor Intel ATX 12 V
Dimensions 150 mm (W) x 190 mm (L) x 86 mm (H)
Fan Information Fan Size 120 mm
Fan Control New Seasonic S3FC
Fan Bearing Double Ball Bearing
Life Expectancy 70,000 at 40 °C, 15 % - 65 % R.H.
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, RCM, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 7 Years
Power Output
AC Input Voltage: 100 V - 240 V
Current: 13-6.5 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 87 A 0.5 A 3 A
125 W 1050 W 6 W 15 W
Total continuous power 1050 W

CABLES

SS-1050XP3

Connector Connector Count Cable Length
Main Power (24/20 pins) 1 1 x 610 mm - modular
CPU (8/4 pins) 2 1 x 650 mm - 8/4pins modular
1 x 650 mm - 8 pins modular
PCIe (8/6 pins) 8 4 x 550 + 100 mm - modular
SATA 14 4 x 400 + 120 + 120 + 120 mm - modular
1 x 300 + 120 mm - modular
Peripheral 5 1 x 400 + 120 + 120 mm - modular
1 x 300 + 120 mm - modular
Floppy 1 1 x 100 mm - modular

Specifications are subject to change without prior notice.
