SEASONIC Platinum Series SS-1200XP3 1200W 80 Plus Platinum Modular Power Supply

SEASONIC Platinum Series SS-1200XP3 1200W 80 Plus Platinum Modular Power Supply

Brand : SEASONIC

Regular price ₱14,424.00
Sale price ₱14,424.00
Regular price ₱16,828.00 -14%
Sale! Sold out

PLATINUM SERIES

The Seasonic Platinum Series achieves extremely high power conversion efficiency and unbelievably tight 2 % voltage regulation.  Every model features a patented DC Connector Module Back Panel with Integrated VRM and LLC/Full-bridge circuit topology. The Platinum series defines what genuine premium power supplies should be by delivering the complete package; ultra-high efficiency, excellent dynamic response, and customizable cable arrangement that can be tailored to meet any individual needs.

  • ATX 12 V
  • Fully modular
  • 80 PLUS Platinum Certified
  • 7 Years Warranty
  • Dimensions: 150 mm (W) x 190 mm (L) x 86 mm (H)
  • Dimensions: 150 mm (W) x 160 mm (L) x 86 mm (H)

FEATURE SUMMARY

  • 80 PLUS® Platinum certified
  • Stable Voltage Regulation (2 %)
  • DC to DC Converter Design
  • S3FC - Fanless until 30 % load
  • Multi-GPU setup
  • Gold plated connectors
  • 7 years warranty

SS-1200XP3

Technical Specifications
80PLUS® Platinum
Form Factor Intel ATX 12 V
Dimensions 150 mm (W) x 190 mm (L) x 86 mm (H)
Fan Information Fan Size 120 mm
Fan Control New Seasonic S3FC
Fan Bearing Double Ball Bearing
Life Expectancy 70,000 at 40 °C, 15 % - 65 % R.H.
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, RCM, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 7 Years
Power Output
AC Input Voltage: 100 V - 240 V
Current: 15 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 100 A 0.5 A 3 A
125 W 1200 W 6 W 15 W
Total continuous power 1200 W



View full details

Description

PLATINUM SERIES

The Seasonic Platinum Series achieves extremely high power conversion efficiency and unbelievably tight 2 % voltage regulation.  Every model features a patented DC Connector Module Back Panel with Integrated VRM and LLC/Full-bridge circuit topology. The Platinum series defines what genuine premium power supplies should be by delivering the complete package; ultra-high efficiency, excellent dynamic response, and customizable cable arrangement that can be tailored to meet any individual needs.

  • ATX 12 V
  • Fully modular
  • 80 PLUS Platinum Certified
  • 7 Years Warranty
  • Dimensions: 150 mm (W) x 190 mm (L) x 86 mm (H)
  • Dimensions: 150 mm (W) x 160 mm (L) x 86 mm (H)

FEATURE SUMMARY

  • 80 PLUS® Platinum certified
  • Stable Voltage Regulation (2 %)
  • DC to DC Converter Design
  • S3FC - Fanless until 30 % load
  • Multi-GPU setup
  • Gold plated connectors
  • 7 years warranty

SS-1200XP3

Technical Specifications
80PLUS® Platinum
Form Factor Intel ATX 12 V
Dimensions 150 mm (W) x 190 mm (L) x 86 mm (H)
Fan Information Fan Size 120 mm
Fan Control New Seasonic S3FC
Fan Bearing Double Ball Bearing
Life Expectancy 70,000 at 40 °C, 15 % - 65 % R.H.
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, RCM, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 7 Years
Power Output
AC Input Voltage: 100 V - 240 V
Current: 15 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 100 A 0.5 A 3 A
125 W 1200 W 6 W 15 W
Total continuous power 1200 W
