SSUPD Meshroom PCI-E 4.0 Riser Cable
SSUPD Meshroom PCI-E 4.0 Riser Cable
Brand : SSUPD
Regular price
₱4,315.00
Sale price
₱4,315.00
Regular price
₱11,000.00
-66%
Unit price
per
Regular price
Couldn't load pickup availability
PCI-E 4.0 Riser Cable is custom fitted for Meshroom S and Meshlicious, fully tested and fully compatible with newly released NVIDIA RTX4000 series GPU, AMD RX7000 series GPU and Intel Z790 motherboards, AMD X670 motherboards.
- Diverse length for different layouts.
- Compatible with PCI-E 4.0 standard.
- Quality hand soldered gold-plated contacts for signal integrity.
- Over 64GB/s (bi-directional) true PCIe 4.0 performance riser via rare shielded extreme high-speed wires and dedicated power lines for lossless signals at range.
Specifications
Cable width
57 mm
Cable length
PCIe Gen 4.0: 145 mm, 175 mm, 270 mm, 385 mm, 440 mm;
PCIe Gen 3.0: 210 mm, 175 mm, 270 mm, 385 mm, 440 mm
PCIe Gen 3.0: 210 mm, 175 mm, 270 mm, 385 mm, 440 mm
PCIe standard
PCIe Gen 4.0 / PCIe Gen 3.0
Cable and bracket color
Matte Black, black powder coated steel
Compatibility
PCIe length support ITX MB
With rear GPU intalled:
145 mm (dual reverse), lowest position not available
270 mm (direct)
With horizontal SFF GPU intalled:
210 mm (female reverse)
270 mm (direct)
145 mm (dual reverse), lowest position not available
270 mm (direct)
With horizontal SFF GPU intalled:
210 mm (female reverse)
270 mm (direct)
PCIe length support ATX MB
With rear GPU intalled:
385 mm (female reverse)
440 mm (female reverse)
With horizontal SFF GPU intalled:
270 mm (direct)
385 mm (female reverse)
440 mm (female reverse)
With horizontal SFF GPU intalled:
270 mm (direct)
PCIe length support MATX MB
With rear GPU intalled:
385 mm (female reverse)
440 mm (female reverse)
With horizontal SFF GPU intalled:
175 mm (direct)
270 mm (direct)
385 mm (female reverse)
440 mm (female reverse)
With horizontal SFF GPU intalled:
175 mm (direct)
270 mm (direct)
PCIe length support MATX/ATX MB with horizontal SFF GPU intalled
Support MATX:
385 mm (female reverse)
440 mm (female reverse)
Support ATX:
440 mm (female reverse)
385 mm (female reverse)
440 mm (female reverse)
Support ATX:
440 mm (female reverse)
GPU max length in ITX build
With rear GPU intalled:
145 mm (dual reverse): 332 mm length and 152 mm width in 4 slots (82mm)
270 mm (direct): 353 mm length and 152 mm width in 4 slots (82mm) with extra feet
With horizontal SFF GPU intalled:
210 mm (female reverse) and 270 mm (direct): 212 mm length in 3 slots (61 mm) with front fan only
145 mm (dual reverse): 332 mm length and 152 mm width in 4 slots (82mm)
270 mm (direct): 353 mm length and 152 mm width in 4 slots (82mm) with extra feet
With horizontal SFF GPU intalled:
210 mm (female reverse) and 270 mm (direct): 212 mm length in 3 slots (61 mm) with front fan only
GPU max length in MATX/ATX build
With rear GPU intalled:
175/270 mm (direct): 314 mm length and 120 mm width in 3 slots (62 mm);
175/270 mm (direct): 325 mm length and 120 mm width in 3 slots (62 mm) with extra feet
With horizontal SFF GPU intalled:
385/440 mm (female reverse): 332 mm length and 152 mm width in 4 slots (82mm)
385/440 mm (female reverse): 353 mm length and 152 mm width in 4 slots (82mm) with extra feet
175/270 mm (direct): 314 mm length and 120 mm width in 3 slots (62 mm);
175/270 mm (direct): 325 mm length and 120 mm width in 3 slots (62 mm) with extra feet
With horizontal SFF GPU intalled:
385/440 mm (female reverse): 332 mm length and 152 mm width in 4 slots (82mm)
385/440 mm (female reverse): 353 mm length and 152 mm width in 4 slots (82mm) with extra feet
GPU max length in MATX/ATX build with horizontal SFF GPU intalled
Support MATX: 385/440 mm (female reverse): 239 mm length in 3 slots (61 mm) Support ATX: 440 mm (female reverse): 239 mm length in 3 slots (61 mm
Note
*GPU baffle not included in length and PCIe power connectors need 15-20 mm space
General
Dimensions (L x W x H)
145mm x 145mm x 33mm
Package dimensions (L x W x H)
225mm x 145mm x 35mm
Net weight
145 mm : 54 g
175 mm : 62 g
210 mm : 68 g
270 mm : 67 g
385 mm : 83 g
440 mm : 87 g
175 mm : 62 g
210 mm : 68 g
270 mm : 67 g
385 mm : 83 g
440 mm : 87 g
Gross weight
145 mm : 109 g
175 mm : 117 g
210 mm : 123 g
270 mm : 121 g
385 mm : 137 g
440 mm : 141 g
175 mm : 117 g
210 mm : 123 g
270 mm : 121 g
385 mm : 137 g
440 mm : 141 g
Warranty
1 year
Package contents
PCIe riser cable
