XFX SPEEDSTER QICK 319 AMD Radeon™ RX 6700 XT BLACK Gaming Graphics Card with 12GB GDDR6 HDMI 3xDP, AMD RDNA™ 2 (RX-67XTYPBDP)

PERFORMANCE TO RULE YOUR GAME
The AMD Radeon™ RX 6700 XT graphics card, powered by AMD RDNA™ 2 architecture, featuring 40 powerful enhanced Compute Units, the all new AMD Infinity Cache and 12GB of dedicated GDDR6 memory, is engineered to deliver ultra-high frame rates and powerhouse 1440p resolution gaming.

GAME CLOCK, UP TO*
2548
BOOST CLOCK, UP TO**
2622
GDDR6 MEMORY SIZE
12 GB
MEMORY CLOCK SPEED
16 GBPS

POWERHOUSE PERFORMANCE FOR 1440P
Get equipped to play the newest games at the highest settings with 12GB of GDDR6 memory and 40 enhanced compute units delivering 1440p gaming at ultra settings with smooth framerates and maximum visual settings.

AIRFLOW AND AESTHETICS
Finding the balance between a good looking card and maximizing it's performance is an art. Where we could improve airflow, we did it, we opened it up while keeping the design clean and cool.

XFX GHOST THERMAL AND COOLING TECHNOLOGIES
XFX's all new Ghost Thermal design cools your GPU better than ever before. Our new design features a straight through airflow venting to significantly improves cooling and compliments open design of the Ghost Thermal floating shroud design. Our new 13 blade fans increase total air flow and provides long lasting quieter operation.

MAXIMIZED THERMAL PADDING
XFX maximizing the cooling effectiveness of our cards by increasing the number of thermal padding throughout the card. This includes thermal pads on VRM's, Memory, and GPU on both sides of the PCB. Ensuring stable high quality performance.

XFX DUAL BIOS READY
We know enthusiast like options, so for our QICK 319 RX 6700 series graphics cards we are offering dual BIOS. Giving a backup BIOS in the case of a failed BIOS update.

AMD SMART ACCESS MEMORY
Get more performance through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCI Express.

13 BLADE TRIPLE DISSIPATION FANS
Our new 13 blade fans increase total air flow and provides long lasting quieter operation. With 2x 90mm and 1x 100mm fans there is more than enough airflow to ensure maximum cooling.

XFX ZERO DB AUTO LOAD SENSING FANS
XFX Fans are equipped to run at the highest possible performance, while our Zero DB fan system will also keep your fans running at efficient RPM in order to minimize annoying fan noise by lowering RPM all the way down to Zero RPM. When the heat is on during intense gaming, our fans will speed up as needed.

AMD INFINITY CACHE
High-performance bandwidth. Up to 96MB of AMD Infinity Cache enables high bandwidth performance at low power, and low latency when gaming.

VIVID VISUALS
AMD Radeon™ RX 6000 Series graphics cards pull you into the action with immersive gaming technologies and support for DirectX® 12 Ultimate. Experience gaming with realistic lighting, shadows, and reflections along with rich detail thanks to DirectX® Raytracing (DXR), variable rate shading (VRS), and AMD FidelityFX features, optimized for AMD RDNA™ 2 architecture. ‍

ULTRA HD SUPPORT
‍The XFX RX 6700 XT is built for high-performance and high resolution gameplay. Experience smooth gameplay performance at 1440p.With support for 8k you are ready for Next-Gen displays. See everything in mind blowing detail without sacrificing performance.

REAL TIME RAY TRACING
AMD Radeon RX 6000 Series graphics cards with enhanced RDNA 2 compute units featuring Ray Accelerators are optimized to deliver real-time lighting, shadow, and reflection realism with DirectX Raytracing, the new standard for next generation gaming visuals to increase visual quality in gaming.

GET A BOOST IN FRAMES FOR YOUR GAMES
AMD FidelityFX Super Resolution (FSR) boosts your frame rates 2.4X on average in FSR supported games with high-quality, high-resolution gaming experiences delivered by AMD Radeon RX 6000 Series graphics cards. Optimize your gaming experience between four presets, ranging from best visual fidelity to maximum performance. Visit https://www.amd.com/en/technologies/radeon-software-fidelityfx-super-resolution/ for more information.

AMD INFINITY CACHE
High-performance bandwidth. Up to 96MB of AMD Infinity Cache enables high bandwidth performance at low power, and low latency when gaming.

AMD SMART ACCESS MEMORY
Get more performance through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCI Express.

HIGH PERFORMANCE 1440P GAMING
With up to 40 enhanced compute units delivery powerhouse performance, 1440p gaming is easily possible at smooth framerates and maximum visual settings.

GDDR6 MEMORY FOR ADVANCED GAMING
Equipped with 12GB of advanced GDDR6 memory to provide high bandwidth performance, enabling 1440p performance for today's most demanding games.

PCI EXPRESS 4.0 SUPPORT
The AMD Radeon™ RX 6000 Series graphics cards feature PCIe® 4.0, with a throughput of 16GT/s which enables two times the bandwidth when compared to PCIe® 3.0

500 MILLION GAMERS PLAY ON AMD RADEON
AMD Radeon™ graphics powers more than 500 million gamers on most of today’s newest gaming devices.

RECOMMENDED FOR ENTHUSIASTS COMPUTER CASES
For optimal performance, the XFX QICK 319 is intended for computer cases sufficient space and airflow. Micro, Mini, and some Mid tower computer cases may not be sufficient for the QICK 319.

AMD RADEON™ IS WINDOWS 11 READY
Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12

XFX 3 YEAR WARRANTY
Even though we trust that our high quality products will continue working at peak performance well beyond the use of it, we want to put our word behind that promise. That is why we offer our 3 Year Warranty with this series of graphics cards. This means that your product is protected by a 3 year limited hardware warranty on manufacturing defects of anything on the card.

SPECIFICATIONS

TECH SPECS

Manufacturer
‍Manufacturer: XFX
Model Number: RX-67XTYPBDP
Product Name: AMD Radeon™ RX 6700 XT
Product Description: XFX SPEEDSTER QICK 319 AMD Radeon™ RX 6700 XT BLACK Gaming Graphics Card with 12GB GDDR6 HDMI 3xDP, AMD RDNA™ 2
Short Description : XFX SPEEDSTER QICK 319 AMD Radeon™ RX 6700 XT BLACK Gaming Graphics Card with 12GB GDDR6, AMD RDNA™ 2
Launch Date: March, 2021
UPC Number: 778656081260

Specifications
‍Bus Type: PCI-E 4.0
Clock Speeds:
Base clock Up to: 2457MHz
Game Clock Up To: 2548MHz*
Boost clock Up to: 2622MHz**
Stream Processors: 2560
Memory Bus: 192bit
Memory Clock: 16 Gbps
Memory Size: 12 GB
Memory Type: GDDR6
Card Profile: 2.6 Slot
Thermal Solution: 3 Fan

*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.

**"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.

Outputs
‍DisplayPort: 1.4 with DSC
HDMI™: 2.1 VRR and FRL
Output : Display Port 3
Output: HDMI 1

Requirements
‍External Power: 2x PCI-E 8pin
Minimum Power Supply Requirement: 650 watt
XFX Recommended Power Supply: XFX 750W PSU

Certifications
RoHS

Package Contents
Quick Installation Guide: 1

Estimated Dimensions & Weights
‍Card Dimension (cm) 32.3 x 13.2 x 5.1
Card Dimension (inch) 12.72 x 5.20 x 2.01
Master Carton Dimensions (cm) 53 x 45 x 46
Master Carton Dimensions (inch) 20.87 x 17.72 x 18.11
Master Carton Weight (Kg) 16.6 est
Master Carton Weight (lb) 36.60 est
Package Dimensions (cm) 42.7 x 21.4 x 12.6
Package Dimensions (inch) 16.8 x 8.43 x 4.96
Package Weight (Kg) 1.86 est
Package Weight (lb) 4.1 est
Units/Carton 8

Technologies
AMD RDNA™ 2 Architecture
DirectX® 12 Ultimate
Hardware Raytracing
FidelityFX
Radeon Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
GDDR6 Memory
PCI® Express 4.0 Support
AMD FreeSync™ Technology*
DisplayPort™ 1.4 with DSC
HDMI™ 2.1 VRR
Video Streaming up to 8K
AMD FidelityFX*
Radeon™ Image Sharpening*
Radeon™ Anti-Lag*
Radeon™ Software
Game Driver Optimizations
OpenGL Support
‍
* Not compatible with Windows 7. For more information on Radeon technologies, visit: AMD.com/gamingdetails

Key Features

Advanced 7nm GPU

PCI Express 4.0 Support

Radeon Image Sharpening
FidelityFX
Radeon Anti-Lag
Microsoft® Windows® 10 Support
Microsoft® DirectX™ 12 Support
7nm Technology
AMD Virtual Super Resolution (VSR)
AMD Relive
AMD FreeSync 2 HDR
AMD Frame Rate Target Control (FRTC)
AMD Eyefinity multi-display technology
AMD Radeon Adrenalin Software
AMD WattMan
Displayport 1.4 w/ DSC
Dolby TrueHD and DTS-HD Master Audio Support
OpenGL Support
OpenCL Support
